BS EN 13709 Y Type Strainer, DN80, PN40, EN 10213 1.0619
Key Specifications / Features
The DN80 PN40 Y-type strainer is designed in compliance with the BS EN 13709 standard, ensuring reliable performance in demanding applications. Crafted from high-quality EN 10213 1.0619 material, the valve body offers durability and strength. Featuring a Y-shaped structure with a mesh size of 0.25 mm, the strainer effectively filters out debris without a drain plug. It is equipped with an RF (raised face) connection, providing a secure and efficient seal for various pipeline systems, making it ideal for use in high-pressure environments.
- Model No.: Kelly-ST-20240921-01
- Hits: 9
- Categories: Pipe Strainer
- Tags: BS EN 13709 Strainer , EN 10213 1.0619 Strainer , Y Type Strainer
Detail Information
On this page
1. Offers excellent pressure and temperature resistance, making it suitable for various operating conditions.
2. Y-shaped filters are typically installed at the inlet of pipeline systems or ahead of key equipment. They can be mounted either horizontally or vertically, providing versatile installation options.
2. Y-shaped filters are typically installed at the inlet of pipeline systems or ahead of key equipment. They can be mounted either horizontally or vertically, providing versatile installation options.
