ASME B16.34 Y Type Strainer, 1 IN, 150 LB, ASTM A182 F22
Key Specifications / Features
The 1-Inch 150 LB Y-Type Strainer is designed in compliance with the ASME B16.34 standard. The valve body is constructed from ASTM A182 F22 material, featuring a Y-shaped design with a bolted body and cover connection. The strainer is equipped with a socket weld (SW) connection.
- Model No.: Kelly-YST-20240810-01
- Hits: 7
- Categories: Pipe Strainer
- Tags: Y Type Strainer , ASME B16.34 Strainer , 1 Inch Strainer
Detail Information
On this page
ASME B16.34 Y Strainer, 1 Inch/DN25, Class 150 LB, ASTM A182 F22 Body, SW Connection.
1. Engineered for easy disassembly and maintenance, minimizing downtime and lowering maintenance expenses.
2. Built with a robust structure and durable materials, ensuring a long service life and reducing the need for frequent replacements and associated costs.
