BS 1868 Swing Check Valve, 300 LB, 8 Inch, ASTM A216 WCB
Key Specifications / Features
The 8-inch 300 LB swing check valve, crafted to BS 1868 standards, features a durable body constructed from ASTM A216 WCB steel combined with STL. This valve incorporates a plug cover and swing-type structure, ensuring reliable performance and effective flow control. It is equipped with a raised face (RF) connection, which provides a secure and leak-proof seal. Designed for robust applications, this valve offers both durability and efficiency in managing fluid flow. As a leading swing check valve manufacturer in China, we deliver high-quality products that meet rigorous industry standards.
- Model No.: Kelly-CV-20240816-03
- Hits: 7
- Categories: Swing Check Valve
- Tags: BS 1868 Check Valve , Class 300 LB Check Valve , 8 Inch Check Valve
Detail Information
On this page
1. The valve boasts a simple structure, facilitating easy replacement or repair of the valve disc and seat, and minimizing maintenance workload.
2. Its straightforward design, with fewer components, results in low manufacturing and maintenance costs, making it ideal for large-scale applications and widespread use.
2. Its straightforward design, with fewer components, results in low manufacturing and maintenance costs, making it ideal for large-scale applications and widespread use.
