10 Inch Ball Valve, A105, ASME B16.34, Class 300, BW End, Gearbox
Key Specifications / Features
China 10 Inch Ball Valve Manufacturer Kelly Supplies 10 Inch Ball Valve, ASTM A105, ASME B16.34, API 6D Standard, Class 300, BW End, Gearbox Operation.
- Model No.: FW BV 09
- Hits: 24
- Categories: Full Welded Ball Valve
- Tags: 10 Inch Ball Valve , ASTM A105N Ball Valve , ASME B16.34 Ball Valve
Detail Information
Valve Description:
Design Standard: API 6D, ASME B16.34.
Body Material: A105.
Nominal Diameter: 10".
Pressure: CL300.
End Connection: BW.
Face to Face: ASME B16.10.
Working Temperature: -29℃~+200℃.
Mode of Operation: Gearbox.
Test and Inspection: API 598.
Product Range:
Body Material: Low Temperature Carbon Steel, Carbon Steel.
Normal Diameter: 2"~60" (DN50~DN1500).
End Connection: BW, Flanged.
Pressure Range: 150lbs~2500lbs(PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃~+200℃.
Design Standard: API 6D, ASME B16.34.
Body Material: A105.
Nominal Diameter: 10".
Pressure: CL300.
End Connection: BW.
Face to Face: ASME B16.10.
Working Temperature: -29℃~+200℃.
Mode of Operation: Gearbox.
Test and Inspection: API 598.
Product Range:
Body Material: Low Temperature Carbon Steel, Carbon Steel.
Normal Diameter: 2"~60" (DN50~DN1500).
End Connection: BW, Flanged.
Pressure Range: 150lbs~2500lbs(PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃~+200℃.
