ISO 17292 Ball Valve, ISO 17292, DN80, PN16, ASTM A105
Key Specifications / Features
The DN80 PN16 Ball Valve is engineered in compliance with the ISO 17292 standard, ensuring top-notch performance and reliability. Crafted from durable ASTM A105, the valve body is designed for demanding applications. It features a full bore and fixed ball structure, providing optimal flow with minimal pressure loss. The valve is equipped with anti-fire and anti-static features, enhancing safety during operation. Its connection conforms to the EN 1092-1 B1 standard, ensuring seamless integration with various systems. Operated by a lever, this ball valve offers straightforward and precise control, making it ideal for a range of industrial applications.
- Model No.: Kelly-BV-20240810-04
- Hits: 7
- Categories: Trunnion Ball Valve
- Tags: ISO 17292 Ball Valve , DN80 Ball Valve , PN16 Ball Valve
Detail Information
On this page
ASTM A105 Trunnion Mounted Ball Valve, Carbon Steel, ISO 17292, DN80, PN16.
1. Trunnion design enhances structural support, enabling the valve to withstand high pressures and temperatures.
2. It evenly distributed sealing forces reduce stress on seals, leading to better sealing, reduced leakage, and longer seal life.
2. It evenly distributed sealing forces reduce stress on seals, leading to better sealing, reduced leakage, and longer seal life.
