CF8 Y Type Ball Valve, BS5351, DN50, PN16, Raised Face, Bare Shaft
Key Specifications / Features
China CF8 Y Type Ball Valve Manufacturer Kelly Supplies CF8 Y Type Ball Valve, BS5351 Standard, DN50, Pressure PN16, Raised Face, Bare Shaft Operation.
- Model No.: CS VB 25
- Hits: 16
- Categories: Cast Steel Ball Valve
- Tags: Y Type Ball Valve , Bare Shaft , ASTM A351 CF8 Ball Valve
Detail Information
Valve Description:
Design Standard: BS5351.
Body Material: CF8.
Nominal Diameter: DN50.
Pressure: PN16.
End Connection: RF.
Face to Face: BS1560.
Working Temperature: -29℃~+200℃.
Mode of Operation: Bare Shaft.
Test and Inspection: BS5146.
Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2"~60" (DN50~DN1500).
End Connection: BW, Flanged.
Pressure Range: 150lbs~2500lbs(PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃~+200℃.
Design Standard: BS5351.
Body Material: CF8.
Nominal Diameter: DN50.
Pressure: PN16.
End Connection: RF.
Face to Face: BS1560.
Working Temperature: -29℃~+200℃.
Mode of Operation: Bare Shaft.
Test and Inspection: BS5146.
Product Range:
Body Material: Carbon Steel, Stainless Steel, Alloy Steel.
Normal Diameter: 2"~60" (DN50~DN1500).
End Connection: BW, Flanged.
Pressure Range: 150lbs~2500lbs(PN16~PN420).
Operation: Lever, Gearbox, Electric, Pneumatic, Electro Hydraulic Actuator, Gas Over Oil Actuator.
Working Temperature: -46℃~+200℃.
